TORQUE (토크)계수에 따른 TORQUE 환산표

[은가비화스너]

TORQUE (토크)계수에 따른 TORQUE 환산표

A중:K = 0.110~0.150

                           축 력   단 위 : kgf

B중:K = 0.150~0.190                         TORQUE 단위:kgfm

토크계수	세트의 등급	F10T
	나 사 호 칭	M16	M20	M22	M24
	축력중앙값(kgf)	11872	18546	23000	26709
0.110		20.9	40.8	55.7	70.5
0.115		21.8	42.7	58.2	73.7
0.120		22.8	44.5	60.7	76.9
0.125		23.7	46.4	63.3	80.1
0.130		24.7	48.2	65.8	83.3
0.135		25.6	50.1	68.3	86.5
0.140		26.6	51.9	70.8	89.7
0.145		27.5	53.8	73.4	92.9
0.150		28.5	55.6	75.9	96.2
0.155		29.4	57.5	78.4	99.4
0.160		30.4	59.3	81.0	102.6
0.165		31.3	61.2	83.5	105.8
0.170		32.3	63.1	86.0	109.0
0.175		33.2	64.9	88.6	112.2
0.180		34.2	66.8	91.1	115.4
0.185		35.1	68.6	93.6	118.6
0.190		36.1	70.5	96.1	121.8
